What is AMD 3D V-Cache? Extra gaming performance unlocked

AMD launched the Ryzen 7 5800X3D in 2022, bringing the world’s first processor with 3D V-Cache to market. It remains one of the best gaming CPUs available in 2023, offering credible competition to AMD’s Ryzen 7000 series and Intel’s Raptor Lake processors. It’s no longer alone, though, with newer Ryzen 7000-series 3D VCache CPUs poised to offer even greater gaming performance.

With AMD’s latest Ryzen 7000 generation now launched, here’s everything you need to know about 3D V-Cache.

What is AMD 3D V-Cache?

AMD Computex 2021 Lisa Su
AMD

AMD 3D V-Cache is a packaging technology that stacks additional layers of cache on top of a CPU. It sounds complex, and from an engineering perspective, it is, but it’s not hard to understand what AMD’s tech is doing. Instead of laying the cache next to the processor, as has been traditionally done, AMD is stacking the cache on top to squeeze more on the chip.

Get your weekly teardown of the tech behind PC gaming
Check your inbox!

It’s a different way to lay out a processor, and thanks to advancements in how CPU makers put components on a chip, AMD is able to squeeze on more cache without making a massive CPU. Originally, 3D V-Cache was restricted to an eight-core CPU in the 5800X3D, however, with the Ryzen 7000 generation, AMD introduced the eight core 7800X3D, the 12-core 7900X3D, and the 16-core 7950X3D.

However, this isn’t the whole picture. While those higher-end CPUs do feature more than eight cores, the 3D V-Cache is only applied to one of their core complex dies (CCD). In the case of the 7900X3D, it has six cores with 3D V-Cache available, clocked at a lower boost clock, while the other CCD doesn’t have the 3D V-Cache, but is able to operate at higher frequencies. The same goes for the 7950X3D, which has eight cores with 3D V-Cache and eight cores running at the higher boost clock.

The idea is to give a gaming advantage, while still having the high-speed cores available for tasks that demand clock speed more than cache. It’s part of why AMD was able to deliver greater productivity performance in certain applications with these CPUs, at least according to its first-party test numbers. It also claims to have worked extensively with Microsoft and game developers to ensure that the unique scheduling needs of such a CPU are met and catered for so that games and applications can best take advantage of these intriguing CPUs.

How does 3D V-Cache work?

Your processor has three levels of cache, with the lowest being L3, or level 3, cache. Each cache level is smaller in size, but faster in speed, acting as a memory chain to your processor that can serve up instructions as they’re needed.

Think about cache like a supply chain. Your RAM is like a national warehouse, the L3 cache is a regional distribution center, and so on through the L2 and L1 caches. For 3D V-Cache, we’re talking about additional L3 cache, the slowest level on your CPU. That’s only relatively slow, though — each cache layer is still significantly faster than your hard drive or RAM.

More L3 cache allows the processor to stream and store more instructions, decreasing the number of times it needs to pull instructions from RAM. With the 5800X3D running at lower clock speeds because of limitations of the 3D V-Cache voltage and temperature thresholds, it was great in gaming, but some tasks suffered. With the Ryzen 7000 3D V-Cache CPUs that offer both high clock speeds on some cores and V-Cache on others, AMD hopes to have solved that problem.

AMD CEO holding 3D V-Cache CPU.
AMD

Why does AMD use 3D V-Cache?

There are a few reasons why AMD would rather make an entire chip line with additional cache rather than put more cache in the CPU itself, which has been the norm up to this point. For starters, 3D V-Cache is more customizable and can be added optionally to processors that would actually benefit from it. Although extra cache does have its use outside games, there are many programs that don’t benefit from having more cache, including benchmarks like Cinebench R23.

Cache is also problematic for manufacturing CPUs. One of the key aspects of making CPUs is the process or node, which determines performance, power efficiency, and transistor density characteristics. Newer nodes allow for physically smaller transistors and thus more compact processors, but cache is much more difficult to shrink than other components in a CPU, such as the cores. Since cache doesn’t benefit from being in cutting-edge nodes, it can be cheaper to just make a cache chip on an older and cheaper node.

Which CPUs have 3D V-Cache?

AMD Ryzen 7000 3D V-Cache spec sheet.
Image used with permission by copyright holder

AMD originally launched the 5800X3D in 2022. This last-generation, Zen 3 CPU has eight cores and 96MB of L3 cache thanks to the additional 64MB of 3D V-Cache. This has now been joined by the new-generation 7800X3D, 7900X3D, and 7950X3D.

AMD Ryzen 9 7950X3D AMD Ryzen 9 7900X3D AMD Ryzen 7 7800X3D AMD Ryzen 7 5800X3D
Cores 16 12 8 8
Threads 32 24 16 16
L2 Cache 16MB 12MB 8MB 4MB
L3 Cache 128MB 128MB 96MB 96MB
Base clock Up to 4.2GHz Up to 4.4GHz Up to 4.4GHz Up to 3.4GHz
Boost clock Up to 5.7Ghz Up to 5.6GHz Up to 5Ghz Up to 4.5GHz
TDP 120W 120W 120W 105W

AMD has managed to have additional cores with this generation’s 3D V-Cache CPUs, though only half of them on each of the top two chips have it available. That makes the 7900X3D an interesting CPU, since it only has six cores with 3D V-Cache available, while both the 7800X3D and 7950X3D have eight apiece.

CPUs from this generation also operate at higher clock speeds across the board, although the top frequencies will be reserved for the cores without the 3D V-Cache. There’s still some sacrifice in clock speed, too, as evidenced by the Ryzen 7 7800X3D.

AMD has enabled some measure of overclocking with this generation, which wasn’t the case with the 5800X3D. AMD has enabled Precision Boost Overdrive (PBO) and AMD’s Curve Optimizer, which together should help enthusiasts raise clock speeds and lower voltages by a small margin — though AMD has said that it doesn’t expect big gains with these features.

Thermal design power (TDP) is flat across all CPUs, which may mean there’s additional overclocking headroom on non-3D V-Cache cores, and that these chips might end up being the most efficient of their generation.

3D V-Cache performance

Cinebench benchmark results for the AMD Ryzen 7 7800X3D.
Image used with permission by copyright holder

AMD originally debuted 3D V-Cache on the Ryzen 7 5800X3D, and as you can read in our Ryzen 7 5800X3D review, it topped gaming performance at the time. Now, AMD has new Ryzen 7000 3D V-Cache CPUs, and they’re repeating what we saw in the previous generation.

The flagship Ryzen 9 7950X3D promises the best of both worlds with chart-topping gaming and productivity performance. It mostly succeeds at the goal, even if it takes a slight backseat to Intel’s Core i9-13900K in some productivity benchmarks, as you can read in our Ryzen 9 7950X3D review.

Photoshop benchmark results for the AMD Ryzen 7 7800X3D.
Image used with permission by copyright holder

The main problem with this chip, however, is its price. At $700 out of the gate and often selling for $800 or more, it’s easily the most expensive mainstream CPU you can buy. Moreover, AMD’s newer Ryzen 7 7800X3D is just as fast when it comes to gaming.

You can read our Ryzen 7 7800X3D review for a full breakdown of performance, but overall, the cheaper processor is just as fast as AMD’s latest flagship. In some games, such as Far Cry 6 and F1 22, it’s even a hair faster.

Overall gaming performance for the Ryzen 7 7800X3D.
Jacob Roach / Digital Trends

Breaking the conversation out to Intel, Team Blue doesn’t have a good answer for 3D V-Cache at the moment, at least in gaming. Outside of that realm, the 3D V-Cache chips struggle a bit due to the overhead imposed by the cache.

A packaging revolution?

Render of an AMD Ryzen chip.
AMD

AMD made a big deal when it launched 3D V-Cache, and for good reason. The 5800X3D was able to go toe to toe with much more powerful processors, and the next-generation Ryzen 7000 variants look set to steal the gaming crown from Intel, even with its rumored 6Ghz 13900KS waiting in the wings.

It’s not yet clear if this is a technology that will benefit everyone that deserves to be part of the more mainstream CPU lines, but it’s clear that gaming sees a big boost. The 3D V-Cache technology also works as a great mid-generation refresh for AMD processors, helping it stay one step ahead of the competition — even if it doesn’t exactly encourage gamers to be early adopters of new AMD hardware.
