Ports and cables are more confusing than they should be. With all the different USB standards, plug types, and speeds, it’s easy to get overwhelmed by the number of options. USB-A and USB-C are the two most common forms of USB, and knowing the differences between the two is essential for understanding what all your devices and peripherals can do.
What is USB-A?
USB Type-A connections refer to the physical design of the USB port. Every USB connection makes up a port in the host device, a connecting cable, and a receptor device. USB-A is a traditional USB host port design and one of the easiest to recognize on devices.
It’s a horizontal port with the bottom portion dedicated to pin connectors. This arrangement creates the infamous, one-sided USB connection that only works with the cable perfectly inserted — no matter how many times you have to try.
Interestingly, there is no USB-B host port. The USB-B connector is the receptor port on the USB device you are connecting to the host computer. Type B connections also are easy to recognize because of their square shape with rounded corners on one side, almost like the shape of a tiny house. USB type B is mainly for external peripherals, with a USB-A connection on one end and a USB-B connection. There are USB-B to USB-B cables, but they’re rarely used.
Note that there are also subsets of this design, like USB Mini-A and USB Micro-A, with different port designs, but these aren’t as important for our current discussion.
What is USB-C, and how does it differ?
USB-C is a newer port type officially announced in 2014, although it took several years for the ports to reach widespread consumer devices, as we see today. Designed to solve many of the old USB-A port problems, USB-C was an entirely new type of USB port. Critical features of USB-C include:
- A slimmer design that fits into a port no matter which direction it’s flipped, designed to replace A, B, mini, and micro USB connections all at once.
- A 100-watt, 20-volt connection is far more powerful than the older port and can handily power even larger devices.
- Potential for a much higher data transfer rate than USB-A.
- Support for power delivery to charge up devices on either end (with the right cables) and charge larger devices.
- Support for video delivery at much higher quality, including transmitting 4K video to a screen.
- Support for alternate modes that allow for lots of different adapters for specific connections like HDMI or VG — or older types of USB connections.
- Potential compatibility with Thunderbolt 3 connections means a USB-C port can double as a Thunderbolt 3 port with extra hardware.
So, USB-C is a better connection?
With the right data standard (see below), the USB-C connection is much faster and more versatile than USB-A. In time, you can expect USB-C connections to replace all older USB-A connections and other ports. This switchover will, however, probably take years.
For now, USB-A shows up alongside the USB type C connector in many computers, primarily to deal with compatibility issues. People may still have an older device, including smartphones, beloved controllers, receivers, TVs, keyboards, and many peripherals that require a USB-A/B connection.
Most people don’t want to buy an adapter to make USB-C backward-compatible with all their stuff. As the use of these older devices fades, USB-C will become the go-to port that everyone knows to look for — and we already see this happening in some sectors.
Where does USB 3.2 fit into this?
USB 3.0 to 3.2 refers to a specific USB protocol for data when it comes to USB connections: Instead of describing the physical port, this refers to the data formats the port can handle. A notable change came with USB 3.0, which required a modification of the USB-A and USB-B designs to gain more capabilities and a faster data transfer speed. USB-A cables that support USB 3.0 and above come with a blue pin protector instead of the standard gray one.
USB 3.2 is divided into two different types. The fully updated version called USB 3.2 Gen 2×2, which is named after both the second generation and how it uses two 10Gbps lanes to reach a total of 20Gbps. The second type is an older USB 3.1 10Gbps standard that, with its latest updates, can also be referred to as USB 3.2 Gen 2.
And just to throw one more wrench into the mix, USB type A and USB-C ports can support various standards, anywhere from USB 2.0 to USB 3.2. There are no universal names for these protocols to make matters more complex, so not everyone uses the same name. For example, USB 3.1 Gen 1 is also called USB 3.0. Fortunately, USB 3.2 is backward-compatible with all other USB connections, although USB-C ports may require an adapter. You also must make sure that your USB cables and devices support 3.1 data capabilities when possible.
If you’re feeling confused, we understand. Luckily, there are only a few simplified, crucial points that you would do best to remember:
- USB-A and USB-C can both have a degree of data standards, up to USB 3.2, which outlines their overall data capabilities.
- USB 3.2 is backward-compatible with other standards, making it an excellent standard for users, although it may call for you to use extra adapters.
- A USB-C connection is the only one that can support the full potential of USB 3.2
- Ensure that all of your external cables, cords, and devices are compatible with the USB data standard. It’s just simple matching: if you get a port with USB 3.2, your cable and connected device must also support 3.2.
- Be prepared: All this is going to be changed when USB4 arrives, with a brand-new name, the latest speeds (up to an amazing 40Gbps), and an attempt to make all these confusing standard names much simpler. USB4 will also be backwards compatible with some older USB ports, so when you see it you may be able to start using it right away.
