HDMI ARC or digital optical: What’s the difference, and which is best for you?

Modern home entertainment is spearheaded by the almighty A/V system, a high-octane amalgamation of TVs, projectors, receivers, speakerssoundbars, and the many standalone components we do our cable and Blu-ray watching, music streaming, and next-generation gaming with. And amidst this medley of wired this-and-that is the HDMI cable tying all things audio and video together. But let’s not forget about digital optical audio cables, too.

Before HDMI ARC arrived, embedding the ability to send digital audio over the same cable as digital video, optical was already around and widely in use as a digital audio A-to-B pathway. But if there was already a ones-and-zeroes audio player in town, why do we need HDMI ARC at all?

As single-wire audio solutions for your A/V peripherals, HDMI ARC and optical are similar in some ways but very different in others. So which of these new connections is the right one for you and your home theater room, and how do you wire everything together correctly? We’ve put together this explainer to answer all these questions and more.

A war of audio capabilities

Klipsch Cinema 800 Dolby Atmos Sound Bar in a room.

As mentioned, fundamentally, both HDMI ARC and optical let you send digital audio from one piece of hardware to another. The idea behind this is to be able to send whatever digital content you plan on enjoying — from your TV to Blu-ray players and game systems — into a larger, better audio system without losing any quality along the way. Without a digital pathway, we’d need to convert all of those ones and zeroes into an analog signal first, and that’s a job best left to our A/V receivers or soundbars.

Whether you’re watching movies and TV shows through your TV directly or using a streaming device, you can think of your TV as being the main hub — everything connects (or is built into) your TV, with a separate sound system as the device you’re sending audio into.

And in terms of how that signal gets from your TV to the audio peripheral, there are two options — HDMI ARC (or ARC for short) and digital optical.

Digital optical: The old hat still fits

The KabelDirekt Optical Digital Audio Cable.

Developed by Toshiba in 1983, the digital optical cable was invented so consumers could transmit digital audio signals from CD and Laserdisc players to an A/V receiver or stereo system. Thanks to the optical cable and its unique connector — known as a TosLink (a shortening of Toshiba Link) connector — we could send a digital audio signal between two components for the first time.

That digital signal is known as SPDIF (Sony/Philips Digital Interface), and it can be sent along an optical cable as a beam of red light, or it can be passed from A to B over good ‘ol coaxial copper RCA cables if your equipment supports it.

SPDIF can deliver uncompressed stereo two-channel sound, also known as PCM, as well as compressed bitstream surround sound formats like Dolby Digital or DTS Surround System. But SPDIF was never intended to carry more information than these digital formats required, and there’s no way to upgrade it. Thus, your optical (or coaxial) digital connection is similarly limited as to what it can do.

Optical can’t pass along higher-bandwidth formats such as Dolby Digital Plus, Dolby TruHD, or DTS:X, because the signal simply cannot them — it would be like trying to fit a six- or eight-lane freeway’s worth of traffic down a two-lane residential street. This means that if you want Dolby Atmos or DTS:X object-based surround sound, an optical cable simply won’t work.

That being said, you can still get non-object-based surround sound with an optical connection — up to 7.1 channels of Dolby Digital or basic DTS — but if you want to experience enhanced formats like Dolby Digital Plus, Dolby True HD, or DTS:X, you need to use HDMI ARC or eARC. Also, if you happen to be into formats like DVD-Audio or SACD, you need HDMI ARC for these formats, too.

And while digital optical is limited to these older formats, that doesn’t mean it sounds bad. You can still get really good-quality surround sound out of an optical connection. So if that’s your only option, then use it!

In fact, the new Sonos Ray soundbar only offers an optical connection, because it doesn’t support Dolby Digital Plus, Dolby True HD, or DTS:X either, so why use HDMI ARC? Yup, optical is still getting used in new products today. But if you want top-quality surround sound with future-proofing built in, HDMI ARC or eARC is the way to go.

Wait, ARC? eARC? Is there a difference?

Yes, and it’s similar to the difference between optical and HDMI ARC. As great as HDMI ARC is from an improved bandwidth point of view, it too is limited. It can support Dolby Digital Plus, which is what virtually every streaming service today uses to deliver high-quality surround sound with or without Dolby Atmos. But that’s where it ends.

If you want to send very-high-bandwidth digital audio formats like Dolby TrueHD, DTS:X, DTS-HD High Resolution Audio, or DTS-HD Master Audio from your TV to your audio gear, you’ll need the additional capacity of HDMI eARC. And while almost any HDMI cable that can support ARC can also support eARC, that is not true of the components you’ll be connecting. Make sure that both your TV and the device you’ve connected it to, have the HDMI eARC label on their respective ports, or it might not work.

HDMI ARC: remote control

The AmazonBasics HDMI cable being used for a laptop.

Besides the enhanced sound quality, using an HDMI ARC connection lets you take advantage of HDMI CEC — or Consumer Electronics Control — which lets you change the volume of your soundbar or A/V receiver with the volume buttons on your TV remote, turn everything in the system on or off at the same time with just one power button, and perform some other clever tricks.

Simply put, if you have the option of using HDMI ARC (or eARC) between your devices, go with this option for the most optimized home theater experience.

Performance you can see and hear

While this may seem obvious, we’d like to take a moment to address the other major calling card of HDMI that digital optical simply cannot touch, which is the ability to send both digital audio and picture from a myriad of sources to your TV, projector, or A/V receiver. Digital optical, on the other hand, is only capable of sending audio from one component to another.

HDMI has always possessed the ability to send digital video and audio from a component to your TV, but the real magic involved in the addition of ARC/eARC is that the same cable can be used to send digital audio back to the same component from the TV. So, one cable, three potential digital signals.

How do you use HDMI and digital optical cables?

Sony Bravia X95K hdmi ports.
Dan Baker/Digital Trends

Connecting both types of wires couldn’t be easier, although HDMI (and optical, to an extent) are going to require a few tweaks in your TV or receiver’s settings.

With optical, just plug one end of the cable into your TV or the optical output of a standalone component and the other end into the optical input of your A/V receiver or soundbar.

With HDMI, simply connect one end of the cable to the HDMI port marked ARC (or eARC) on your A/V receiver or soundbar (or in very special circumstances, a 2021 Apple TV 4K) and the other end to the port marked ARC (or eARC) on your TV. From there, though, you need to go into your TV’s audio settings and check a few things.

For those of you using HDMI ARC, you might want to first go make sure that HDMI CEC is turned on, if that’s an option. Some systems won’t turn ARC on until you turn CEC on. Next, go into your audio output settings and choose either HDMI ARC or digital optical.

For those of you using the optical connection, you’ll want to go one step further and choose either PCM or bitstream. Choose PCM if you have a two-channel soundbar, even if it does virtual, fake surround sound. And choose bitstream if you have a surround sound soundbar that decodes Dolby or DTS so that it gets a legit surround sound signal.

All this said, if you do have HDMI ARC on your TV and your audio device, my advice is to use that over optical. It’s superior, no doubt about it.

That’s all there is to it!
